Fully automatic Photooptical Particle Analysis from 0 up to 200 mm

HAVER CPA 5 GRAVIOPT for particle sizes from 0 up to 200 mm

The HAVER CPA 5 GRAVIOPT combines the advantages of the Photooptical Particle Analysis and gravimetrical measurement. The material to be analysed will be classified by a purpose built HAVER sieving machine, whereby the cut point is freely selectable. Afterwards the analysed sieve overflow and also the sieve underflow are scaled. The result is a complete sieve curve.

Right in the middle

  • Installable in current production as an online device.
  • Integration into existing installations is possible.
  • Both, the measuring unit as well as the HAVER CPA Software are prepared for an online connection to a PLC system.

Further advantages at a glance

  • Covering of a wide grain spectrum (finest fraction is ascertainable).
  • Pneumatic cleaning as standard.
  • Analysis of all particle sizes and particle shapes in real time
    (HAVER REAL TIME).
  • Reproducible measuring results.
  • Fully automatic particle size analyses.

Technical data

Measuring range0 - 200 mm
Operating voltage230 Volt, 50 Hertz or 115 Volt, 60 Hertz
Chute width450 mm
CameraCCD-line camera
Lighting moduleLED
Protection classIP 54
Interfacesdigital IO-Ports, GigE, RS 232
Line resolution4096 Pixel
Pixel frequency60 MHz
Dimensions5400 x 720 x 1720 mm (L x W x H)
Weightapprox. 530 kg

Application examples for the HAVER CPA 5 GRAVIOPT

The fully automatic HAVER CPA 5 GRAVIOPT has been designed with a HAVER sieving machine, a HAVER CPA unit and two scales for gravimetrical measurement.



The material with particle sizes up to 200 mm to be analysed is classified by a HAVER sieving machine with chosen cut point. The sieve overflow is analysed photooptically and discharged to a first scale. The mass fraction of the sieve underflow will determined directly by a second scale.



The HAVER CPA Software evaluates and combines the total distribution of the sample with the information from the photooptical and gravimetrical measurements.

Application examples:

  • Coke
  • Coal
  • Recycling materials
  • Industrial rocks and materials
